SLDL6500 Belt Integrated Monitoring Instrument
The SLDL6500 is a high-precision intelligent integrated monitoring terminal specifically designed for belt conveyor systems. The device captures high-precision, high-resolution depth data streams and color data streams in real time, enabling real-time 3D color point cloud reconstruction of the measurement scene. Additionally, the system integrates a high-performance edge computing unit and delivers multiple advanced functions, including automatic conveyor belt speed measurement, material height profiling, real-time material flow statistics, large lump detection with alarms, belt misalignment detection with alerts, and conveyor belt crack detection.
- Product Introduction
Solidat Applied Technologies Ltd. is one of the leading manufacturers and suppliers of sldl6500 belt integrated monitoring instrument in China, also supports customized service. Please feel free to buy high quality products in stock here and get quotation from our factory. Good service and reasonable price are available.
The SLDL6500 Belt Integrated Monitoring Instrument is built upon advanced machine vision and real-time 3D reconstruction technologies. It integrates a multi-sensor system to construct dense point cloud sequences with authentic color textures. Equipped with a built-in high-performance edge computing unit, the device utilizes proprietary core algorithms to process dynamic 3D point clouds in real time, accurately calculating conveyor belt speed and material accumulation profiles, thereby achieving high-precision measurement of both instantaneous and cumulative flow rates.
Furthermore, the system performs intelligent recognition of point cloud features within the 3D spatial domain, effectively detecting abnormal conditions such as oversized materials and belt misalignment. The entire measurement process is non-contact. Through multi-dimensional data fusion and analysis, the system directly outputs precise statistical results and real-time alarm information at the edge, ultimately enabling intelligent monitoring and accurate measurement of bulk material conveying processes.
Lump Coal Detection
Conveyor Belt Misalignment Detection
Conveyor Belt Crack Detection
Product Features
• Measurement accuracy of up to millimeters.
• Integrated edge computing unit providing powerful edge computing capabilities.
• Supports real-time conveyor belt speed measurement.
• Supports material height measurement on the conveyor belt.
• Supports real-time flow rate measurement on the conveyor belt.
• Supports conveyor belt misalignment (run-off) detection.
• Supports large object detection on the conveyor belt.
• Supports Conveyor Belt Rip Detection
• Supports obtaining flow statistics via TCP protocol.
• IP65 protection rating for industrial-grade dust and water resistance.
| Data Interface | Gigabit Ethernet |
| Power Supply | 12V~24V DC |
| Power Consumption | 18W |
| IP Rating | IP65 |
| Temperature | Operating: -10 ~ 50°C Storage: -10 ~ 60°C |
| Humidity | 20% ~ 85% |
| Recommended Installation Height | 1.2m ~ 1.5m |
| Conveyor Belt Coverage Range | 0 ~ 3m |
| Supported Conveyor Belt Speed | 0 ~ 6m/s |
| Protocol Support | TCP, Modbus TCP, MQTT |
