SLDL3500 RF Admittance Switch
The CapDetect RF admittance switch measures the admittance value between the center rod and the installation wall through high-frequency signals, thereby determining whether the measuring rod is covered by the material. CapDetect employs a three-terminal technology and a five-layer concentric structure to eliminate the influence of cable temperature effects and installation capacitance accumulation on the measurement results. CapDetect offers three types: the SLDL3510 standard type, the SLDL3520 non-adjustable type, and the SLDL3530 flat type.
- Product Introduction
Solidat Applied Technologies Ltd. is one of the leading manufacturers and suppliers of sldl3500 rf admittance switch in China, also supports customized service. Please feel free to buy high quality products in stock here and get quotation from our factory. Good service and reasonable price are available.
The CapDetect radio frequency admittance switch measures the admittance value between the center pole and the mounting wall through high-frequency signals to determine the measurement pole.
Whether it is covered by materials. CapDetect uses three-terminal technology and a five-layer concentric structure to offset the effects of cable temperature, installation capacitance, and hanging materials on measurement results.
CapDetect SLDL3510 RF Admittance Switch
1.The CapDetect technology effectively prevents the influence of wire wrapping and capacitor installation.
2.The SLDL3510 has a self-learning function, which can intelligently recognize environmental changes and make matching adjustments.
3.It has strong versatility and can be used for the measurement of various conductive and non-conductive media, including liquids, viscous substances, particles, powders, and fly ash.
4.The SLDL3520 is completely self-tuning and ready to use upon installation.
5.It can withstand temperatures up to 815 degrees and is suitable for various harsh working conditions.
6.Multiple output options are available: relay output (DPDT/SPDT)/non-contact switch, transistor output, two-wire output (8mA/20mA), Namur output, etc.
7.It is equipped with 1000V spark protection, surge suppression, and anti-static 4kv/8kv.
8.The power supply range is 21~35VDC and 30~265VAC, with the power supply design suitable for various power supply environments.
9.The SLDL3530 is in tablet form and can be installed flush against the wall, effectively preventing mechanical damage. 19
Measure the Solid Benefits…
10.Applicable to both liquid and solid measurements
Application:
Liquid: Conductive liquid or insulating liquid (including liquefied gas)
Pulp: Conductive pulp and insulating pulp
Particles: Grains, plastic sheets, coal, etc.
Interface: Interface between two liquids with different dielectric constants
Powder: Plastic powder, cement, fly ash, etc.
