SLDL5524 High Temperature Cable Guided Wave Radar
High-temperature and high-pressure guided wave radar is a measuring instrument based on the principle of time travel. Radar waves run at the speed of light. The running time can be converted into a level signal through electronic components. The high temperature cable guided wave radar working probe emits a high-frequency pulse and propagates along the cable-type probe.
- Product Introduction
Product Overview
High-temperature and high-pressure guided wave radar is a measuring instrument based on the principle of time travel. Radar waves run at the speed of light. The running time can be converted into a level signal through electronic components. The high temperature cable guided wave radar working probe emits a high-frequency pulse and propagates along the cable-type probe. When the pulse encounters the surface of the material, it is reflected and processed by the electronic information processing unit of the instrument and converted into a level signal.
SLDL5524 high-temperature and high-pressure guided wave radar is suitable for liquid level measurement under high-temperature and high-pressure working conditions and complex process conditions. Even in an environment with strong foam, accumulation, and steam, the measurement accuracy is not affected. SLDL5524 high temperature cable guided wave radar is an economical solution for liquid level measurement.
Product Features
Due to the use of advanced microprocessors and echo processing technology, high-temperature and high-pressure guided wave radar can be applied to various complex working conditions, multiple process connection methods and detection component types, making this series of cable guided wave radar level meters suitable for various complex working conditions and applications. Such as: high temperature, high pressure and small dielectric constant media, etc.
Using pulse working mode, the guided wave radar level meter has extremely low transmission power and can be installed in various metal and non-metal containers without harming the human body and the environment.
Advantages
• Guided debugging ensures simple, time-saving and reliable setting.
• Gapless hygienic design is simple and has reliable cleanliness.
• Cable guided wave radar level meter is very easy to install and maintain.
•High temperature cable guided wave radar can be shortened for measurement: electrode standard is simple to ensure the flexibility of the plan
performance parameters
Application scope: liquid
Measurement distance: cable-type range 75m; rod-type range 6m
High-temperature and high-pressure guided wave radar antenna: single rod or single cable
Measurement accuracy: ±2mm
Working environment temperature: -40～200℃
Working environment pressure: -1~40bar (-100~4000KPa)
Signal output: 4-20mA/HART two-wire/four-wire, Profibus PA, Foundation Fieldbus, Modbus protocol, GPRS/CDMA remote, Bluetooth (optional)
On-site display: LCD display
High-temperature and high-pressure guided wave radar process connection:G1 1/2A/G2A/1 1/2NPT/flange (optional)
