SLDLF2510‑2M‑600H Acoustic Doppler Current Profiler (ADCP)
SLDLF2510‑2M‑600H Acoustic Doppler Current Profiler (ADCP) Mainly applied for flow velocity and discharge measurement in river channels up to 120 m in width.
- Product Introduction
Solidat Applied Technologies Ltd. is one of the leading manufacturers and suppliers of sldlf2510‑2m‑600h acoustic doppler current profiler (adcp) in China, also supports customized service. Please feel free to buy high quality products in stock here and get quotation from our factory. Good service and reasonable price are available.
SLDLF2510‑2M‑600H Acoustic Doppler Current Profiler (ADCP)
SLDLF2510‑2M‑600H Acoustic Doppler Current Profiler (ADCP) Mainly applied for flow velocity and discharge measurement in river channels up to 120 m in width.
Product Characteristics
‑ Easy‑to‑operate current profiler, capable of acquiring velocity profile, water‑level and other data parameters.
‑ Powerful digital signal‑processing technology; velocity profile supports up to 256 measurement bins.
‑ Simultaneously measures vector angles of layered flow velocity and outputs forward / reverse flow direction.
‑ Built‑in underwater ultrasonic water‑level sensor and static pressure water‑level sensor; external water‑level sensor is also supported.
‑ Communication interfaces: RS485 (standard Modbus protocol), SDI‑12, RS‑232, RS‑422.
‑ Supports input of field parameters and irregular cross‑section diagrams for calculating water‑cross‑section area and flow discharge.
‑ Integrated attitude sensor for easy installation with minimal civil‑engineering work.
‑ Anti‑theft function: built‑in GPS+4G communication module. When the device is powered off or displaced, position information will be automatically sent to pre‑configured mobile‑phone clients for device recovery.
‑ Low‑power‑consumption design for long‑term field deployment.
‑ User‑friendly configuration, diagnosis and commissioning software.
‑ Military‑grade high‑temperature‑resistant chips adopted.
Technical Parameters
| Item | Specification |
| Model | SLDLF2510‑2M‑600H |
| Operating Frequency | 600 kHz |
| Acoustic Path | Planar‑array dual‑beam |
| Horizontal Ultrasonic Beam Angle | 130° |
| Beam Spread Angle | 1.4° |
| Maximum Ping Rate | 10 Hz |
| Measurement Range | 1‑120 m |
| Blind Zone | 0.8 m |
| Max Number of Measurement Bins | 256 |
| Bin Size | 0.5‑5 m, dynamically adjustable |
| Measurement Accuracy | ±0.5%FS ±1.0 mm/s |
| Velocity Resolution | 0.001 m/s |
| Velocity Measurement Range | ±10 m/s (max. 20 m/s) |
| Temperature Sensor Range | ‑25℃‑75℃ |
| 3‑D Gyro‑Attitude Sensor (Optional) | True north ±2°, pitch & roll ±0.5° |
| Attitude‑Sensor Accuracy | ±0.5° |
| Temperature Accuracy | ±0.4℃ |
| Ultrasonic Water‑level Measurement | 0‑20 m, ±0.1%FS |
| Ceramic‑pressure Water‑level Measurement | 0‑20 m, ±0.1%FS |
| External Water‑level Input | Supported |
| Measurement Interval | 1‑60 min adjustable |
| Data Output | Water‑level, layered velocity, average velocity, cross‑section area, discharge, etc. |
| Operating Temperature | ‑10℃‑60℃ |
| Storage Temperature | ‑20℃‑70℃ |
| Rated Submergence Depth | 50 m underwater |
| Protection Grade | IP68 |
| Operating Voltage | DC 7‑15 V |
| Power Consumption | Sampling＜2.9 W |
| Communication Protocol | RS485 (standard Modbus); SDI‑12; RS‑232; RS‑422 |
| Sensor Dimensions | 158×220×200 mm |
| Weight (in air) | 3.8 kg |
| Weight (in water) | 0.65 kg |
| Reliability MTBF | ＞25000 h |
