OEM MonoScan EA10P/10F Ultrasonic Level Measurement
MonoScan is an ultrasonic, continuous-level measurementgauge of mono-block construction (combining the sensor andelectronic components in a single unit). MonoScan measuresthe height of both liquids and solids accurately.
- Product Introduction
Solidat Applied Technologies Ltd. is one of the leading manufacturers and suppliers of oem monoscan ea10p/10f ultrasonic level measurement in China, also supports customized service. Please feel free to buy high quality products in stock here and get quotation from our factory. Good service and reasonable price are available.
Introducing MonoScan
MonoScan is an ultrasonic, continuous-level measurementgauge of mono-block construction (combining the sensor andelectronic components in a single unit). MonoScan measuresthe height of both liquids and solids accurately.
It can be used for the following measurement tasks:
--Liquid tanks with calm surfaces
--Solids tanks that are dust-free
--Open channel flow measurement
MonoScan has a range of up to 15 m (49.21 ft) with anaccuracy of 0.25% within that range.
MonoScan is available in three models:
--MonoScan L for liquids (Standard Range/Short Range)
--MonoScan S for solids (Standard Range/Short Range)
--MonoScan O for open channels (Standard Range/Short Range)
MonoScan dimensions:
MonoScan Specifications：
Accuracy：0.25% of measuring range
Resolution：1 mm (0.04")
Beam angle ：5°@ 3db point
Ambient temperature compensation：Automatic
Measuring Ranges：
|
MonoScan L for liquids |
Short Range |
0.25 m — 5 m |
|
0.82 ft — 16.4 ft |
||
|
Standard |
0.6 m — *15 m |
|
|
1.96 ft — 49.2 ft |
||
|
MonoScan S for solids |
Short Range |
0.25 m — 5 m |
|
0.82 ft — 16.4 ft |
||
|
Standard |
0.6 m — 8.5 m |
|
|
1.96 ft — 27.8 ft |
||
|
MonoScan O for open channels |
Short Range |
0.25 m — 5 m |
|
0.82 ft — 16.4 ft |
||
|
Standard |
0.6 m —*15 m |
|
|
1.96 ft — 49.2 ft |
||
|
* Depending on the sensor type |
||
Mechanical Specifications：
Enclosure：IP 65/ IP 67, Mono-block construction.
Plastic enclosure: ABS+UV
Ex version: Conductive ABS +UV
Pollution degree：2 (as per IEC61010)
Insulation category：II (as per IEC61010)
Wetted parts：Sensor body: PolyProp. PVDF, optional.
Stainless steel for Liquid model; Coated
aluminum for Solid/Liquid model.
Operating temperature：-40°C to + 70°C
(-40°F to +158°F)
Mounting：2" BSP or 2" NPT
Operating pressure：Atmospheric
Dimensions：289 x 107 x 85 mm
(11.38 x 4.21 x 3.35")
Weight：Up to 1.4 kg (3.08 lb)
Electrical Specifications：
Display：Integral LCD, four digits.
Loop current：4—20 mA, 750 Ω @ 28 VDC
Supply：12—28 VDC (CE certified)
Certificates：CE—EMC,FM-Safety, FCC.
ATEX: EX ia IIC T4
FM: Class 1 Division I Group A, B, C, D T4.
