External Clamp Type Multi Parameter Analysis System

Introducing our latest product - the External Clamp Type Multi-Parameter Analysis System, designed to meet the analytical needs of a wide range of industries. Our product is engineered with the most up-to-date technology, making it an indispensable tool for professionals seeking accurate and efficient data analysis.



The measurement principle of the SonicAnalyst multi-parameter analysis system is that the mechanical wave generated by the vibration source will attenuate when it passes through the material.



The degree depends on the measurement channel and the density of the substance. When the measurement channel is constant, the attenuation is a function of the density of the substance; the difference between the travel time of the mechanical wave and the countercurrent travel time is a function of the fluid flow and flow rate; the speed of mechanical wave transmission , is a function of the internal fluid pressure.



The SonicAnalyst system can monitor the material density, flow rate, pressure and other parameters in the pipeline without contacting the detected object.

Measurement, providing multi-parameter output. The SonicAnalyst system is especially suitable for use in high concentration, highly corrosive and toxic situations.





- Suitable for highly corrosive, highly viscous, toxic media measurement.

- Accurately measure slurry density/concentration, flow and pressure of wet desulfurization system.

- Non-contact measurement, avoiding the disadvantages of wear, corrosion and blockage caused by contact measurement.

- Simple installation, no need to set bypasses or cut off pipelines, no need to install switches, valves, cleaning devices.

- Maintenance free, no snag points, no frequent calibration or overhaul.

- Wide range ratio, it can measure the density of medium with low flow rate and the density of medium with high flow rate.

- Non-contact probe, long service life, 3-5 times that of contact probe.



Our product enables users to analyze data quickly and accurately with minimal effort. It allows for easy and instant data sharing, thereby improving collaboration and decision-making. Additionally, the External Clamp Type Multi-Parameter Analysis System is easy to use, making it accessible to a wide range of professionals, irrespective of their technical background.



Our product finds applications across various industries, including agriculture, pharmaceuticals, food processing, and environmental studies. It is ideal for monitoring pH, temperature, salinity, and dissolved oxygen levels. It is also suitable for tracking and processing data on water quality, and assessing the impact of contaminants on aquatic life.



Our External Clamp Type Multi-Parameter Analysis System is a valuable asset for professionals seeking precise and efficient data analysis. Its cutting-edge features and versatility make it a superior solution for a range of analytical applications, while its user-friendly design ensures that anyone can use it easily. With our product, you can confidently carry out analytical tasks with precision and ease.



Model	SLDA2110
Measurement range	0~200.00mg/I (0~20%), 0~400.00mgmg/I
Measurement mode	Process mode and real-time mode
Self-diagnosis	Signal strength, operation/outage, full pipe/empty pipe
Display	Density. Temperature, Waveform, Operation/Stop, Full/ATC
Resolution	100mg/I (0.01%)
Accuracy	±1% or ±2000mg/I
Repeatability	±1%
Output	4...20mA, load 250Ω (load range 100-750Ω) Relay output: 3SPDT (5A, 250VAC) Digital signal: RS232, RS485
Data storage time	400 days
Power supply	100~240V AC, 10~26VDC
Temperature	-20~70°C
Protection class	IP67
